Product Hightlights
Auto parts with a variety of carbon steel, silicon steel, stainless steel, alloy steel, spring steel, aluminum alloy, titanium alloy, galvanized sheet, baking plate, galvanized sheet and other alloy sheet and pipe. The device is widely used in auto parts, car body, car door frame, car trunk
Specifications
Application:Mobile phone battery, jewelry, electronical parts and components, sensor, watch, precision machines, communication equipment, artwork, handwork.
Condition:New
Cooling Mode:Water cooling circle system
Control System:Microcomputer program control
Place of Origin:Hubei, China (Mainland)
Brand Name:OV Laser
Certification:CE
Warranty:2 years
Laser Wavelength:1064nm
Applicable Material:Metal and some non-metal
Power Supply: 380V/50Hz or 60Hz , 220V/50Hz or 60Hz
Laser Repetition Frequency:≤50Hz
Field Lens:Singapore Wavelength
Name:500W Fiber Robotic Laser Welding Machine for Automotive Car Parts
Supply Ability
80 Set/Sets per Year
Packaging & Delivery
Standard wooden case
Port
Shanghai, Ningbo, Guangzhou or your port
Lead Time :10 - 30 working days
Item Model | OV FW500R |
Mechanical Arm | |
Working Area | Max 100mm/1400mm/1800mm Optional |
Motion Structure | 6-axis standalone multi-joint type |
Weight | 165KG |
Install Method | Floor stand/ Ceiling air |
Fiber Laser Welding Machine Configuration | |
Laser Power | 150W/300W/500W |
Laser Wavelength | 1064nm |
Laser Type | ND:YAG pulse |
Optic Fiber Port | 1-4pcs |
Light Range | 0.1-0.4mm |
Welding Depth | ≤7mm |
Pulse Frequency | 0-50HZ |
Light Size | 0.2-4.0mm |
Monitor System | High Precise CCD Red Light Indicator |
Control System | JT CNC2000 |
Output Focus Dis | 80mm/110mm/150mm/200mm |
Voltage | 380V±10%50Hz |
Cooling Way | Integration Forced Smart Water Cooling |
Weight | 125KG(With Cooling System) |
Dimension Size | (L×W×H) 3000×3000×1500mm |
